Screen printing machine

1. All positions are equipped with Taiwan Yangming photoelectric sensors, ensuring accurate positioning and excellent performance.

2. Automated robotic loading, unloading, and rewinding for continuous, efficient production with reduced labor.

3. The conveyor table is equipped with a vacuum suction system, and driven by a servo motor for higher transmission accuracy.

4. The squeegee vertical movement adopts a gapless guide column structure, ensuring smooth and stable operation to improve printing quality.

5. The squeegee horizontal movement uses a 400W servo motor with dual linear guides, suitable for high-precision printing.

6. The screen frame lifting adopts guide column structure, ensuring high precision and smooth operation.

7. The conveyor dimensions are approximately 2000mm × 850mm × 1560mm.

8. Printing modes such as off-contact or fixed screen printing can be set according to customer requirements to improve efficiency.

9. Single or double printing cycles can be set according to workpiece requirements, enabling fully automatic operation.

10. The whole machine is controlled by a PLC and inverter system, ensuring stable performance.

11. Equipped with a special shock absorption device for stable operation.

12. The operation panel uses a touchscreen interface, offering quick response and easy operation.

13. Two preset programs: single-cycle printing and fully automatic printing.

14. Adopts advanced pneumatic components with strong power and long durability.

15. Once set, the program can be stored in memory.

16. The conveyor is driven by a 750W servo motor with vacuum suction function.
